Schneider Mvs32h3mf5l 3200a 65ka Mvs Standard Open Type Power Switch

Schneider Open Type Power Switch Product Features Product series: EasyPact MVS Series: EasyPact Product name: MVS32H Product group: MVS32H Product or component type: Circuit breaker Device application: Distribution Pole description: 3P Protected pole description: 3P 3d Network type : AC Rating code : H Suitability for insulation : Yes conforming to IEC 60947-2 Usage category : Category B Trip unit name : ET5S Trip unit technology : Electronic Trip unit rating : 3200 A Supplementary Features Mains frequency : 50/60 Hz Control type : Manual operating Mounting Type: Fixed Mounting support: Base plate Rail Connection position: Horizontal Vertical Position of connection: Rear [In] nominal current: 3200 A at 40 ?C [Ui] nominal insulation voltage: 1000 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] nominal impulse withstand voltage : 12 kV conforming to IEC 60947-2 [Ue] nominal operating voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 Circuit breaker CT value : 3200 A Breaking capacity : 65 kA Icu at 220…440 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] nominal service breaking capacity : 65 kA (Ics) at 220…440 V AC 50/60 Hz conforming to IEC 60947-2 50 kA (Ics) at 690 V AC 50/60 Hz conforming to IEC 60947-2 Mechanical durability: 20000 cycles (with maintenance) conforming to IEC 60947-2 10000 cycles (without maintenance) conforming to IEC 60947-2 Electrical durability: Category B: 5000 cycles 440 V AC 50/60 Hz without maintenance conforming to IEC 60947-2 Category B: 2500 cycles 690 V AC 50/60 Hz without maintenance conforming to IEC 60947-2 Connection distance: 115 mm without separator Contact position indication : Yes [Icm] nominal short-circuit making capacity : 143 kA (Icm) at 220…440 V AC 50/60 Hz conforming to IEC 60947-2 [Icw] nominal short-time withstand current : 65 kA (1 sec) at 220…440 V AC 50/60 Hz conforming to IEC 60947-2 50 kA (1 s) at 690 V AC 50/60 Hz conforming to IEC 60947-2 36 kA (3 s) 440/690 V AC 50/60 Hz conforming to IEC 60947-2 Trip unit protection functions: LSI Protection type: Overload protection (long-term) Short-term short-circuit protection Instantaneous short-circuit protection Fault indication: Overload Internal fault Short-circuit Long long-term opening setting type lr: Adjustable 9 settings Long-term opening setting range: 0.4…1 x In Long-term delay setting type: Adjustable 9 settings [tr] long-term delay setting: 0.5?24 s at 6 x Ir Short-term trip setting type Isd : Adjustable 9 settings [Isd] short-term trip setting range : 1.5…10 x Ir Short-term delay setting type : Adjustable 5 settings [tsd] short-time delay setting range : 100?400 ms Instant opening setting type li: Adjustable 9 settings Instant opening setting range: 2…15 x In Closed Area selective locking ZSI: With Current sensor degree range: 1000/4000 A Maximum cut-off time: 25 ms Maximum closing response time: 70 ms Height: 352 mm Width: 422 mm Depth: 297 mm Product weight: 60 kg Environmental Conditions Standards: IEC 60947-2 Product certifications: IEC CCS CCC GOST IP protection degree: IP40 Pollution degree:4 Conforming to IEC 60664-1 Nominal operating ambient temperature: -5?70 ?C Ambient air temperature for storage: -40?85 ?C without control unit -25?85 ?C with control unit
