Schneider Ez9f43163 Easy9 Series Type C 1x63a Automatic Fuse

Name: Schneider Ez9f43163 Easy9 Series Type C 1x63a Automatic Fuse
Brand: Schneider
SKU: 8248 3606480580444
Availability: InStock

Add to Quote to know Prices

Add to wishlist

Compare

78 People watching this product now!

SKU: 8248 3606480580444 Categories: Electrical, EM.com, Automation and Switchgear Materials, Switchgear Materials, Electrical Fuses, Automatic Fuses Brand: Schneider

Description

Schneider Automatic Fuse Product Features Series: Easy9 Device application: Distribution Product or component type: Miniature circuit breaker Product group: Easy9 MCB Poles: 1P Number of protected poles: 1 [In] nominal current: 63 A Network type: AC Trip unit technology: Thermal Magnetic Slope code: C Breaking capacity: 3000 A Icn at 230 V AC 50/60 Hz conforming to IEC 60898-1 5000 A Icn at 127 V AC 50/60 Hz conforming to IEC 60898-1 Insulation compliance : Yes conforming to IEC 60898-1 Supplementary Specifications Mains frequency : 50/60 Hz [Ue] nominal operating voltage : 230 V AC 50/60 Hz Magnetic trip limit : 5…10 x In [Ics] nominal service breaking capacity : 3 kA 100 % Conforming to kV IEC 60898-1 Contact position indicator: Yes Control type: Toggle On-device signaling: Without Mounting Type: Pluggable Mounting support: DIN rail 9 mm screw pitch: 2 Height: 81 mm Width: 18 mm Depth: 66.5 mm Colour: Gray (RAL 7035) Mechanical durability: 10000 cycles Electrical durability: 4000 cycles Connections – terminals: Tunnel type terminal (top or bottom) 1?25 mm? hard Tunnel type terminal (top or bottom) 1?16 mm? flexible Tightening torque: 3.5 Nm upper or lower Ambient Conditions Standards: IEC 60898-1 Product certifications: CE IP protection degree: IP20 conforming to IEC 60529 Pollution degree: 2 Tropical climate: 2 Relative humidity: 95 % at -25?60 ?C Nominal Operating ambient temperature: -25?60 ?C Storage ambient conditions: -40?85 ?C
