Schneider Electric Mvs40h3mf5l Ep Mvs Cb 4000a 65ka 3p Mf Et5 Fixed Manual Circuit Breaker 3606480540738

Main Product Range Easypact Mvs Range Easy Agreement Product Name Mvs40H Device Short Name Mvs40H Product or Component Type Switch Device Application Distribution Pole Description 3P Protected Poles Description 3P 3D Network Type Ac Breaking Capacity Code H Compliance with Insulation Yes, Use in accordance with Iec 60947-2 Category Category B Trip Unit Name Et5S Trip Unit Technology Electronic Trip Unit Rating 4000A Supplementary Network Frequency 50/60Hz Control Type Manually Operated Mounting Mode Fixed Mounting Support Base Plate Rail Mounting Position Horizontal Vertical Mounting Location Rear [In] Rated Current 40 ?C’ De 4000 A [Ui] Rated Insulation Voltage Conforming to Iec 60947-2 1000 V Ac 50/60 Hz [Uimp] Rated Impulse Withstand Voltage Conforming to Iec 60947-2 12 Kv [Ue] Rated Working Voltage Conforming to Iec 60947-2′ 690 V Ac 50/60 Hz Circuit Breaker Ct Value 4000A Exceeding Capacity 65 Ka Icu at 220…440 V Ac 50/60 Hz, Conforming to Iec 60947-2 [Ics] Rated Service Breaking Capacity 65 Ka ( Ics) 220…440 V Ac at 50/60 Hz Conforming to Iec 60947-2 50 Ka (Ics) at 690 V Ac at 50/60 Hz Conforming to Iec 60947-2 Mechanical Strength Iec 60947-2′ Conforming to 20000 Cycles (With Maintenance) Conforming to Iec 60947-2 10000 Cycles (Without Maintenance) Electrical Durability Category B: 5000 Cycles 440 V Ac 50/60 Hz Without Maintenance Conforming to Iec 60947-2 Category B: 2500 Cycles 690 V Ac 50/60 Hz Maintenance Free Compliant with Iec 60947-2 Connection Pitch 115 Mm Without Emitter Contact Position Indicator Yes [Icm] Rated Short Circuit Capacity 220…440 143 Ka (Icm) at V Ac 50/60 Hz ) Conforming to Iec 60947-2 [Icw] Rated Short Term Withstand Current 65 Ka (1 S) 220…440 V Ac at 50/60 Hz Conforming to Iec 60947-2 50 Ka (1 S) 690 V At 50/60 Hz Ac Conforming to Iec 60947-2 36 Ka (3 S) 440/690 V At Ac 50/60 Hz Conforming to Iec 60947-2 Trip Unit Protection Functions L Thermal Protection Type Short Term Short Circuit Protection Instantaneous Short Circuit Protection Overload Protection (Long Term) Fault Indicator Overload Internal Fault Short Circuit Long Term Start Setting Type Ir Adjustable 9 Settings Long Time Accumulation Setting Range 0.4…1 X In Long Term Delay Setting Type Adjustable 9 Settings [Tr] Long Term Delay Setting Range 6 Adjustable 5 Settings [Tsd] Short Term Delay Setting Range 100?400 Ms Instant Pickup Setting Type Ii Adjustable 9 Settings Instant Receive Setting Range 2…15 Certificates Ccs Gost Iec Ccc Ip Protection Degree IP40 Pollution Degree 4 Conforming to Iec 60664-1 Ambient Air Temperature for Operation -5?70 ?C Ambient Air Temperature for Storage -40?85 ?C Without Control Unit -25?85 ?C Packaging Units with Control Unit Package Unit Type 1 Pce Number of Units in Package 1 1 Package 1 Weight 38 Kg Package 1 Height 42 Cm Package 1 Width 35 Cm Package 1 Length 50 Cm
