Schneider Atv12h055m2 0.55kw Speed ??Controller

Product Features Product destination: Asynchronous motors Component name: ATV12 Internal fan: Without Network number of phases: 1 phase Motor power kW: 0.55 kW Motor power hp: 0.75 hp Line current: 8 A at 200 V 6.7 A at 240 V Speed ??range: 1?20 IP degree of protection: IP20 without cover plate on the upper part Product series: Altivar 12 Product or component type: Variable speed drive Product-specific application: Simple machine Communication port protocol: Modbus [ Us] nominal supply voltage : 200…240 V – 15…10 % EMC filter : Integrated Supplementary Features Supply frequency : 50/60 Hz +/- 5 % Type of connector : 1 Modbus Physical interface for RJ45 (front side) : Modbus for 2-wire RS 485 Transmission frame : Modbus for RTU Transmission rate : 4800 bit/s 9600 bit/s 19200 bit/s 38400 bit/s Number of addresses : 1?247 for Modbus Communication service : Read standby registers (03) 29 word Write single registers (06) 29 word Write multiple registers (16) 27 word Read/write multiple registers (23) 4/4 word Read device identification (43) Continuous output current: 3.5 A at 4 kHz Maximum transient current : 60 s for 5.3 A Speed ??controller output frequency : 0.5?400 Hz Braking torque : Up to 70% of the nominal motor torque without braking resistor Output voltage : 200…240 V 3-phase Electrical connection : Terminal, clamping capacity: 3.5 mm?, AWG 12 (L1, L2, L3, U, V, W, PA, PC) Tightening torque: 0.8 Nm Insulation: Electricity between power and control Supply: Internal supply for reference potentiometer: 5 V DC (4.75?5.25 V), 11 V (case 1) Sampling time: Logic input for 20 ms, tolerance +/- 1 ms Analog input for 10 ms Linearity error: +/- 0% of maximum value, Analog input for 3 Analog output type : AO1 software-configurable voltage: 0…10 V, impedance: 470 Ohm, resolution 8 bit AO1 software-configurable current: 0…20 mA, impedance: 800 Ohm, resolution 8 bit Digital output type: Logic output LO+, LO- Protected relay output R1A, R1B, R1C 1 K/A Minimum switching current: 5 mA at 24 V DC for logic relay Maximum switching current: 2 A 250 V AC inductive cos phi = 0.4 L/R = 7 ms logic relay 2 A 30 V DC inductive cos phi = 0.4 L/R = 7 ms logic relay 3 A 250 V AC resistive cos phi = 1 L/R = 0 ms logic relay 4 A 30 V DC resistive cos phi = 1 L/R = 0 ms logic relay Braking to stop: With DC injection,
