Malkan Mcp01 Pneumatic Pocket Cover Ironing Press

* It is a computer (PLC) controlled touch panel: 5.7″ TFT color LCD screen, 320x 240 pixel resolution, 1ad.usb 2.0 input (program receiving feature on the desktop), animation applied, CE, UL, MIC certified, 140 different programs, 32 MB RAM, Turkish and English standard programming languages, error warning diagnostic feature, ability to manually control the functions of the machines on the screen, program copying feature, feature of counting the number of ironed jobs, coating time warning. * Works with central steam, vacuum and air * It works with 220 V monophase electricity. * The apparatus can be adjusted according to the source of pockets of all sizes. * The pockets are softened with steam and pressed, and the seams are ironed to the desired fineness. * The ironed pockets are automatically pushed forward between the molds with a pushing apparatus. * The upper and lower molds are European * It has a precision mold design with advanced technology CNC surface processing. Technical InformationCapacity (piece/h)100-130Electricity (V)230Resistance Power (kW)Motor Power (kW)Pump Power (kW)Steam Input (“)1 /2″Steam Outlet (“)1/2″Air Inlet (“)1/2″Vacuum Inlet (“)1-1/2″Steam Consumption (kg/s)12Air Consumption (lt/d)18Steam Pressure (bar) )5 – 6.Air Pressure (bar)5 – 6.Net Weight (kg)215Packaged Weight (kg)270Net Dimension (cm)120x114x160Packaged Dimension (cm)130x124x170
